What is the Cube Low-Layer API?

With the advent of the STCube initiative, ST completely redesigned the SDK for the STM32 series introducing the Hardware Abstraction Layer (HAL) library and throwing out of the windows the old Standard Peripheral Library (SPL), which was very popular in the ST community despite of the fact it lacked many features related to more recent and powerful STM32 MCUs. However, the HAL library has attracted a lot of criticism over the years, both because it suffered of too many bugs during the first years and - more important - because it does not represent a good example of well optimized code for the development of embedded applications. The CubeHAL is really a not-performant library, but for one simple reason: it is designed to be abstract and to simplify the porting of user code between MCUs of the same series and MCUs of different STM32 series. This led to a library full of if and then and full of unnecessary code when working with a very specific microcontroller. But this is the price to pay when you want to streamline the development process and - more important - the adoption of a given complex microcontroller architecture like the STM32 portfolio. The HAL APIs are split into two categories: generic APIs, which provide common and generic functions for all the STM32 series, and extension APIs, which include specific and customized functions for a given line or part number. The HAL drivers include a complete set of ready-to-use APIs that simplify the user application implementation. The HAL drivers are feature-oriented instead of IP-oriented. For example, the timer APIs are split into several categories following the IP functions, such as basic timer, capture and pulse width modulation (PWM). The HAL driver layer implements run-time failure detection by checking the input values of all functions. Such dynamic checking enhances the firmware robustness. In the recent years, ST answered to strong criticism of the library’s performances by introducing the Cube Low-Layer (shortened LL) set of drivers. As the name suggest, the LL library is born to be very optimized, leaving to the programmer the responsibility to deal with very specific characteristics of the given STM32 series and the given P/N. The LL drivers offer hardware services based on the available features of the STM32 peripherals. These services reflect exactly the hardware capabilities and provide atomic operations that must be called by following the programming model described in the product line reference manual. As a result, the LL services are not based on standalone processes and do not require any additional memory resources to save their states, counter or data pointers. All operations are performed by changing the content of the associated peripheral registers. Unlike the HAL, LL APIs are not provided for peripherals for which optimized access is not a key feature, or for those requiring heavy software configuration and/or a complex upper-level stack (such as USB). LLbased code is essentially a sequence of C macros that will be expanded in a series of statements with a very limited usage of branches and unpredictable statements from the performance point-of-view. This book will not cover topics related to the LL library. It would require a completely different approach to the text and a strong focus on just few STM32 P/N. This book aims to be generic and to provide an overview of the most relevant features to start designing powerful and complex electronic boards. If you need to control every single aspect of a given peripheral to reach the most optimized code, then the LL library is what you need. But, at the first instance, I suggest you start designing the firmware by using the CubeHAL and then moving to the next step, unless you are a very experienced firmware developer.
